September 14, 2022

Data-at-Rest Build vs. Buy: Flexibility

When a new vehicle is being planned and designed, engineers, system architects, program managers, and acquisition personnel typically debate three procurement options for the subsystems:

  • Design their own subsystem and build it themselves
  • Have a contractor build the subsystem
  • Locate and buy a commercial off-the-shelf (COTS) subsystem

Each approach may get you to the same goal, but each has positive and negative aspects along the way. Those decisions can only be made internally. The white paper Data-At-Rest Build vs. Buy Considerations for Deployed Storage Devices suggests some considerations that should be introduced in any such debate or trade study.

The white paper focuses on data-at-rest (DAR) devices known as network-attached storage (NAS) or network file servers. These NAS devices are Ethernet-based and allow network clients to use the device as local storage. A NAS example is shown in Figure 1.

Figure 1 – Curtiss-Wright DTS1 NAS Example
Figure 1 – Curtiss-Wright DTS1 NAS Example

This blog focuses on one of those considerations: flexibility. The other considerations are lead time, loaners, encryption, quality, reliability, export, cost, and risk. The perspective is that of a defense contractor in the United States.

Why does Flexibility matter?

For a U.S. defense contractor, the flexibility consideration may matter a great deal. The wrong decision will limit the possible use of the DAR device on another program or vehicle.

The benefits of flexibility or re-use are listed below, and likely the reader can think of more reasons to support re-use.

  • Training
  • Spare parts or systems
  • Cost per unit
  • Non-recurring engineering (NRE) avoidance

NOTE: All the following benefits apply to NAS devices, whether designed by in-house personnel, by a subcontractor, or by a COTS vendor.

Training

With any new device or system, the training consideration will have two aspects:

  • Design personnel
  • Maintenance personnel

Design personnel

Design personnel are those engineers and planners responsible for the vehicle architecture and all the systems and subsystems. While network protocols (NFS, CIFS, FTP, HTTP, iSCSI) are all industry standards, each NAS device will have its unique interface. The example NAS in Figure 1 has a unique command line interface (CLI).

The CLI is accessed through either the gigabit Ethernet (1GbE) ports or the serial RS232 port. The CLI includes 30 commands that control device administration, login authentication, port configuration, video stream control, removable memory cartridge reset, front panel control, and many other functions.

A person can send commands using a simple ASCII terminal emulator or ASCII scripts. The terminal emulator mode is usually used for initial training and familiarization. The scripts are embedded into the system for control during vehicle deployment. All functions of the example NAS can be controlled by the CLI.

Once learned, experience design personnel could quickly re-use the same example NAS in a new system. Existing scripts could be re-used that have been proven to work in deployment. Such re-use would save time and money.

Maintenance personnel

The same arguments hold for maintenance personnel. The difference is that maintenance personnel would not write scripts to control the NAS during use or deployment.

Maintenance personnel does need to check the NAS system before and after missions. They would use the built-in test (BIT) and similar commands to test the NAS.

They may also be asked to update the software in NAS. The updated software can be received by email and injected into the NAS with a particular command. Software updates would likely be performed at a service or maintenance depot.

Once you understand how to maintain a NAS, it would be beneficial to re-use the NAS to take advantage of the existing training and experience.

Spare Parts and Systems

Spare versions of any NAS device (or any device) must be purchased to support the deployed vehicle. A device may need to be removed for a variety of reasons.

A device may stop operating due to an internal failure. So, a spare must be inserted in the place of a dead device.

A device may act intermittent or unreliable. This status may be found by the device itself during the BIT operation. Again, a spare unit must be inserted in place of the flaky device.

A device may need to have the software updated. A software update may be required to an issue discovered or may be dictated by a regulatory agency like National Information Assurance Program (NIAP), which may have found a vulnerability with the encryption system. The NAS device will almost certainly have to be removed and returned to a depot for the software update. In that case, a spare unit will be inserted in its place to keep the vehicle operating.

Cost Per Unit

The cost per unit can be reduced if a NAS device is flexible enough to be re-used in another vehicle or application. Flexibility may result from various network protocols being designed into a NAS device. The example NAS supports many network protocols, including NFS, CIFS, FTP, HTTP, PXE, iSCSI, and RTP. This adaptability or flexibility allows the NAS to be used in many applications from UAV, USV, UUV, fighter, helicopter, and ISR.

For in-house designed and built NAS devices, the cost per unit will decrease as more units are manufactured simultaneously. If the electronics manufacturing is available in-house, the volume production will show up just the same as if the unit were built by an external contract manufacturer (CM).

This ‘economy of scale’ holds for units purchased from a COTS vendor. COTS vendors will offer volume discounts if you buy more than a few of one NAS device. Most COTS vendors use CMs to build their NAS devices. The volume discounts from the CM are passed along to the end customers.

As the flexible NAS device is designed into more systems, the volume of purchases increases, and discounts are available.

NRE Cost Avoidance

If a flexible NAS is re-used in more systems, a new NAS does not have to be designed. This means that no NRE will have to be expended. That capital can then be invested elsewhere in the company.

A side benefit of re-using an existing NAS device (and thus no NRE) is that technical risk will be reduced. New designs always have technical risks. Sometimes those flaws can show up late in the program or even during deployment. Technical risks affect the program schedule.

Summary

Whether a NAS device is designed by in-house personnel, an outside design contractor, or a COTS vendor, always consider the possibility of re-use of the NAS device.

Ask yourself some questions:

  • Does the NAS fit only the current program needs?
  • Does it have protocol support that might be used in other programs?
  • Does it support basic protocols like NFS, CIFS, FTP, and HTTP?
  • Can the NAS device support remote booting of network clients using PXE?
  • Can the NAS support block transfers using iSCSI protocol?
  • Can the NAS accept H.264 files from cameras via RTP?
  • Can the NAS be monitored with SNMP?

A flexible NAS device re-used in multiple programs will provide long-term benefits in training, maintenance, cost per unit, and NRE cost avoidance. Benefits like these will add up for your company over time.

[1] Built-in test may also be known as built-in self-test (BIST)
