Networked from Ground to Air - ITC 2018 Demo

This video gives an overview of the “Networked from Ground to Air” demo that was shown at ITC 2018.

It features Curtiss-Wright’s industry-leading airborne data acquisition system (DAS) supporting emerging new standards with Chapter 7 and iNET components, a high-speed Ethernet-based architecture that enables line-of-sight communications to enable flight test engineers to reconfigure test articles during the mission. For example, the data recorder, camera sources, parameters, and image downlink bit-rates can be modified remotely. The demo showcases Curtiss-Wright’s latest hardware, including high-speed DAUs, switches, recorders, rugged IP cameras, and multi-mode transceivers.





    Download the Aerospace Instrumentation Brochure

    Download the Brochure

    Related Products

    Data Acquisition Units
    Data Acquisition

    We've used our decades of program experience providing full-system solutions to develop a comprehensive portfolio of rugged signal conditioning, data acquisition, data multiplexing, and PCM encoder systems for terrestrial and space environments.

    Flight Test Switches
    Flight Test Switches

    Our compact, deterministic flight test switches have been qualified to reliably deliver high-speed, real-time data with a wide temperature operation.

    RF & Flight Safety
    RF & Flight Safety

    Field-proven in programs worldwide, our radio frequency (RF) and wireless systems provide reliable and accurate transmission of telemetry, digital, wideband, and video data for applications such as flight-, space-, and remote ground-based applications

    Test & Monitoring Recorders
    Test & Monitoring Recorders

    From miniature avionics bus recorders to high-speed, high-capacity units with customizable interfaces, we use our decades of experience designing and manufacturing flight test and monitoring recorders to deliver solutions that meet the newest standards.

    HD Camera for FTI Applications
    Cameras & Accessories

    Our broad portfolio of highly rugged, field-proven camera and video acquisition solutions efficiently and reliably capture, convert, route, transmit, record, and display images.

    Video Transcript

    DATA ACQUISITION

    Axon: Powerful, Compact and Flexible DAU

    • 500 Mbps throughput performance-proven
    • Remote mountable modules with 10 m link distance
    • iNET, Chap 10 UDP and DARV3 support

    Protecting Investments

    • The system can integrate DAUs from different families to reuse a massive catalog of modules

    HIGH-SPEED SWITCHES

    Curtiss-Wright Ethernet Switches

    • Proven experience with Ethernet systems designed for flight test
    • Time gateways (IEEE-1588, IRIG, GPS) and Grandmasters
    • Support for chapter 7 and 10
    • Simple to use with a shallow learning curve

    Also Available Now: NSW-16GT-1

    • 4 x 10 Gb, 12 x 1 Gb ports
    • Data from 1 Gb ports can be aggregated onto the 10 Gb ports to send to 10 Gb recorder

    HIGH-SPEED RECORDERS

    ADSR

    • Multiple GbE Ports
    • Can record any Ethernet traffic including DARv3, Chapter 10, iNET-X, IENA, PCAP, etc.
    • Simple to use – our configuration is highly automated with our software. Very shallow learning curve

    Accepting orders now: nREC-7000

    • Can handle 10 Gb at line rate – sustained recording
    • Next-generation 10 Gb data recorder
    • 2 slots for media (initial capacity of 6 TB per media)
    • Can record any Ethernet traffic including DARv3, Chapter 10, iNET-X, IENA, PCAP, etc.

    HD AND HS CAMERAS

    Trusted High Speed and HD Flight Test Camera Provider

    • Proven in the harshest conditions (is this TS, replace with ADV)
    • Complete infrastructure supports dozens of synchronized cameras
    • Optimized for space-constrained platforms

    Network IP Cameras

    • 1920 x 1080 (60 fps)
    • H.264 or H.265 Encoding
    • Video is Captured Directly onto the Network
    • Logical Routing using Existing Switch Architecture

    DATA CONVERSION AND TELEMETRY

    Network Gateway

    • Converts data for transmission from Ethernet to PCM
    • Supports DARv3, iNET TmNS, IRIG-106 Chapter 4/7
    • Mode switching changes data streams to optimize downlink efficiency

    Multiband Transmitter

    • L, S & C-Band in one unit, ultra-high efficiency, LDPC and Space-Time Coding

    iNET AND CONTROL

    Bi-directional Ethernet link, TmNS compatible

    • Extends the aircraft Ethernet network to the ground
    • Data from the network to be received on the ground directly as Ethernet packets without having to convert to PCM first
    • Supports reconfiguring of the triband transmitter while in flight via SNMP messages

    Control and reconfigure hardware e.g.

    • Change frequency of transmitters
    • Switch video streams
    • Configuring your network traffic remotely
