The KAM/CHS/04L is a compact four user-slot KAM-500 chassis, which along with the housing and backplane, includes a KAM/PSU/006 power supply unit.
Features
- Power supply unit and four user-slots
- 18 to 40 VDC isolated power supply
- Rugged aluminum housing
- 8 MHz x 16-bit digital backplane
- Operates as master or slave in a distributed system
Applications
- Flight test instrumentation systems
The NET/SWI/101 is an 8-port airborne Ethernet switch designed for operating in harsh environments. Each port is configurable for 10BaseT, 100BaseTX, and 1000BaseT link speeds or auto-negotiate over copper wiring, supporting straight-through or cross-over cables.
The KAD/VID/106 is an H.264 video encoder card that converts one of three composite analog video inputs.
The KAD/MAT/101 allows you to run your own programs based on a dual-core C6000DSP+ARM9 microcontroller. It provides high-performance DSP functions.
KAD/ADC/136 is used to condition & digitize up to 8 analog channels.
The KAM/CHS/03F is a compact three-user-slot KAM-500 chassis, which along with the housing and backplane, includes a KAM/PSU/008 power supply unit.
The KAM/CHS/04L is a compact four user-slot KAM-500 chassis, which along with the housing and backplane, includes a KAM/PSU/006 power supply unit.
The KAM/CHS/13U is a thirteen user-slot Acra KAM-500 chassis that includes a power supply module that regulates power supplies for the backplane.
KAM/CHS/04L Acra KAM-500 Chassis, Narrow Form - 4 User-Slots
The KAM/CHS/04L is a compact four-user-slot Acra KAM-500 chassis, which along with the housing and backplane, includes a KAM/PSU/006 power supply unit.
The backplane has four slots for user modules, which are polarized to prevent the insertion of the backplane controller module. The backplane has power supply lines and the standard 16-bit address/data bus with read/write control lines. The only ICs on the backplane are demultiplexers for user-module select signal.
The KAM/CHS/04L does not contain any ±7V lines for excitation.
